Operating Parameters

Special Features

This range provides a higher efficiency with lower maintenance. Development of this new range followed an extensive consultation with major users. This has produced an advanced pump which provides total reliability and reduced life cycle cost. We utilizes the well-proven "lean production system". This single flow,lean manufacturing process with dedicated production units means less wastage and greater efficiency, enabling us to provide the highest standard pumps and components.

Design Features

Impeller :
Impeller is firmly secured to the shaft by a key positioned by shaft sleeves and both locked in place by shaft sleeve locknuts external to the stuffing box.

Shaft :
Machined from high quality steel. The shaft is sturdily proportioned to minimize deflection and provide long reliable service.

Sleeves :
Sleeves are provided to protect the shaft and ensure longer shaft life. Neck Ring : Designed with appropriate clearances and materials to minimize leakages while ensuring a long impeller life.

Improved Hydraulics :
Unique hydraulic passage design for optimum performance.

Stiff Shaft Design :
Large diameter shaft supported on a short bearing span minimizes shaft deflection, prolonging seal and bearing life.

Simple Maintenance :
Standard pumps cartridge bearings and seals can be removed without displacing top half casing.

Increased Component Life :
More corrosion allowance offers better corrosion protection and optimum lifetime operation.

Enhanced Performance :
Replaceable wear ring and bush reduce leakage.

Increased Efficiency :
Standard pumps coating on casing internals optimizes performance and prolongs "as new" efficiencies.

Low Hydraulic Loads :
Diametrically opposed volute design reduces hydraulic loads extending seal and bearing life.


Salient Features
